@<1523701070390366208:profile|CostlyOstrich36>
I've updated the instance type to t3a.large.
The issue persisted.

Then possibly it is another reason. Need to search for in the ES logs

ok. Currently the ebs is 15 GB, is there a recommended size?

ClearML Task: created new task id=f08b012bce42420dba7cd166668f5e4b
2025-05-20 09:54:59,251 - clearml.Task - INFO - No repository found, storing script code instead
ClearML results page: /projects/184c6e8651d94b9088ae60ae3a9c8ace/experiments/f08b012bce42420dba7cd166668f5e4b/output/log
2025-05-20 12:55:02
ClearML Monitor: GPU monitoring failed getting GPU reading, switching off GPU monitoring
Starting the training.

....

ClearML Monitor: Could not detect iteration reporting, falling back to iterations as seconds-from-start
2025-05-20 13:02:08
2025-05-20 10:02:08,177 - urllib3.connectionpool - WARNING - Retrying (Retry(total=2, connect=2, read=5, redirect=5, status=None)) after connection broken by 'ConnectTimeoutError(<urllib3.connection.HTTPConnection object at 0x76f683ccb670>, 'Connection to ec2-13-217-109-164.compute-1.amazonaws.com timed out. (connect timeout=300.0)')': /
2025-05-20 10:02:08,178 - urllib3.connectionpool - WARNING - Retrying (Retry(total=2, connect=2, read=5, redirect=5, status=None)) after connection broken by 'ConnectTimeoutError(<urllib3.connection.HTTPConnection object at 0x76f683cc9810>, 'Connection to ec2-13-217-109-164.compute-1.amazonaws.com timed out. (connect timeout=300.0)')': /
2025-05-20 10:02:08,178 - urllib3.connectionpool - WARNING - Retrying (Retry(total=2, connect=2, read=5, redirect=5, status=None)) after connection broken by 'ConnectTimeoutError(<urllib3.connection.HTTPConnection object at 0x76f683ccb6a0>, 'Connection to .compute-1.amazonaws.com timed out. (connect timeout=300.0)')': /
2025-05-20 13:04:25
2025-05-20 10:04:25,347 - urllib3.connectionpool - WARNING - Retrying (Retry(total=1, connect=1, read=5, redirect=5, status=None)) after connection broken by 'ConnectTimeoutError(<urllib3.connection.HTTPConnection object at 0x76f683c32bf0>, 'Connection to .compute-1.amazonaws.com timed out. (connect timeout=300.0)')': /
2025-05-20 10:04:25,348 - urllib3.connectionpool - WARNING - Retrying (Retry(total=1, connect=1, read=5, redirect=5, status=None)) after connection broken by 'ConnectTimeoutError(<urllib3.connection.HTTPConnection object at 0x76f683c32c20>, 'Connection to .compute-1.amazonaws.com timed out. (connect timeout=300.0)')': /
2025-05-20 10:04:25,348 - urllib3.connectionpool - WARNING - Retrying (Retry(total=1, connect=1, read=5, redirect=5, status=None)) after connection broken by 'ConnectTimeoutError(<urllib3.connection.HTTPConnection object at 0x76f683c33040>, 'Connection to .compute-1.amazonaws.com timed out. (connect timeout=300.0)')': /
2025-05-20 13:06:48
2025-05-20 10:06:48,615 - urllib3.connectionpool - WARNING - Retrying (Retry(total=0, connect=0, read=5, redirect=5, status=None)) after connection broken by 'ConnectTimeoutError(<urllib3.connection.HTTPConnection object at 0x76f683c32da0>, 'Connection to .compute-1.amazonaws.com timed out. (connect timeout=300.0)')': /
2025-05-20 10:06:48,616 - urllib3.connectionpool - WARNING - Retrying (Retry(total=0, connect=0, read=5, redirect=5, status=None)) after connection broken by 'ConnectTimeoutError(<urllib3.connection.HTTPConnection object at 0x76f683c33f40>, 'Connection to .compute-1.amazonaws.com timed out. (connect timeout=300.0)')': /
2025-05-20 10:06:48,616 - urllib3.connectionpool - WARNING - Retrying (Retry(total=0, connect=0, read=5, redirect=5, status=None)) after

curl -XGET "localhost:9200/_cluster/allocation/explain?pretty"
curl: (7) Failed to connect to localhost port 9200 after 0 ms: Couldn't connect to server

Looks like elastic is failing to access a shard. Do you have visibility into machine utilization? How much RAM is elastic consuming?

Also, is this the entire error repeating or is there more context?

On what host did you run the curl command?

While on the host you can run some ES commands to check the shards health and allocations. For example this:

curl -XGET "localhost:9200/_cluster/allocation/explain?pretty"

It may give more clues to the problem

Also, it would be great if you could add a recommendation for EBS size in this guide ( None ),
The Elastic Search issue happened with 8 GB, and was resolved with 15 GB.

I tried deleting all the underlying resources: ec2 & ebs, and recreating it again.

I assume that ec2-13-217-109-164.compute-1.amazonaws.com is the ec2 instance where the API is running?
Are you using the files server or S3 for storage? Can you verify on the storage itself that the artifacts are actually uploaded and are downloadable?

I have been rerunning it since yesterday. The error persists.

I can try one more time though.

That's a big context!
In general, I'm using standard functions; the script is running in SageMaker pipeline.
The model, however, is a composite, and consists of multiple primitive ones.

task = Task.init(
    project_name="icp",
    task_name=f"model_training_{client_name}",
    task_type=Task.TaskTypes.training,
    auto_connect_frameworks={'matplotlib': True, 'tensorflow': False,
                             'tensorboard': False,
                            'pytorch': False, 'xgboost': False, 'scikit': False, 'fastai': False,
                            'lightgbm': False, 'hydra': True, 'detect_repository': True, 'tfdefines': False,
                            'joblib': False, 'megengine': False, 'catboost': False, 'gradio': False
    },
    output_uri=False
)

task.set_script(repository=repo_url, branch=branch_name, working_dir="./", commit=commit_id)
task.set_parameter("commit_id", commit_id)

task.connect_configuration()

output_model = OutputModel(task=task, name="trained_model")
output_model.update_weights(register_uri=s3_model_uri)

....

task = Task.current_task()
if task is None:
    print("Warning: No ClearML task found. Metrics will not be logged to ClearML.")
    logger = None
else:
    logger = task.get_logger()

logger.report_matplotlib_figure()
logger.report_scalar()

Did you try to run your job again?

No, it says that it does not detect any problematic shards. Given that output and the absence of the errors in the logs I would expect that you will not get the error anymore

s3

It's the entire error repeating.
And, this happens at the end of the script.

I'm using the recommended instance (t3.large).

And are you still getting exactly this error?

<500/100: events.add_batch/v1.0 (General data error: err=1 document(s) failed to index., extra_info=[events-log-d1bd92a3b039400cbafc60a7a5b1e52b][0] primary shard is not active Timeout: [1m], request: [BulkShardRequest [[events-log-d1bd92a3b039400cbafc60a7a5b1e52b][0]] containing [index {[events-log-d1bd92a3b039400cbafc60a7a5b1e52b][f3abecd0f46f4bd289e0ac39662fd850], source[{"timestamp":1747654820464,"type":"log","task":"fd3d00d99d88427bbc576cba53db062d","level":"info","worker":"b1193fbdd662","msg":"Starting the training.\nClearML Monitor: GPU monitoring failed getting GPU reading, switching off GPU monitoring","model_event":false,"@timestamp":"2025-05-19T11:40:21.919Z","metric":"","variant":""}]}] and a refresh])>

@<1722061389024989184:profile|ResponsiveKoala38> I'm looking at the logs now (used "docker logs clearml-elastic").

The status seemed to had transitioned, but the it's not clear the error.

{"@timestamp":"2025-05-20T08:36:18.412Z", "log.level": "INFO", "message":"setting file [/usr/share/elasticsearch/config/operator/settings.json] not found, initializing [file_settings] as empty", "ecs.version": "1.2.0","service.name":"ES_ECS","event.dataset":"elasticsearch.server","process.thread.name":"elasticsearch[file-watcher[/usr/share/elasticsearch/config/operator/settings.json]]","log.logger":"org.elasticsearch.reservedstate.service.FileSettingsService","elasticsearch.cluster.uuid":"lvIPB_h3RiWqbCvCA-1dbw","elasticsearch.node.id":"wEMvgjW3SUSt8Y8ls7aEyw","elasticsearch.node.name":"clearml","elasticsearch.cluster.name":"clearml"}
{"@timestamp":"2025-05-20T08:36:19.068Z", "log.level": "INFO", "message":"Node [{clearml}{wEMvgjW3SUSt8Y8ls7aEyw}] is selected as the current health node.", "ecs.version": "1.2.0","service.name":"ES_ECS","event.dataset":"elasticsearch.server","process.thread.name":"elasticsearch[clearml][management][T#1]","log.logger":"org.elasticsearch.health.node.selection.HealthNodeTaskExecutor","elasticsearch.cluster.uuid":"lvIPB_h3RiWqbCvCA-1dbw","elasticsearch.node.id":"wEMvgjW3SUSt8Y8ls7aEyw","elasticsearch.node.name":"clearml","elasticsearch.cluster.name":"clearml"}
{"@timestamp":"2025-05-20T08:36:19.360Z", "log.level": "INFO",  "current.health":"GREEN","message":"Cluster health status changed from [RED] to [GREEN] (reason: [shards started [[events-plot-][0]]]).","previous.health":"RED","reason":"shards started [[events-plot-][0]]" , "ecs.version": "1.2.0","service.name":"ES_ECS","event.dataset":"elasticsearch.server","process.thread.name":"elasticsearch[clearml][masterService#updateTask][T#1]","log.logger":"org.elasticsearch.cluster.routing.allocation.AllocationService","elasticsearch.cluster.uuid":"lvIPB_h3RiWqbCvCA-1dbw","elasticsearch.node.id":"wEMvgjW3SUSt8Y8ls7aEyw","elasticsearch.node.name":"clearml","elasticsearch.cluster.name":"clearml"}
{"@timestamp":"2025-05-20T08:36:48.250Z", "log.level": "INFO", "message":"[queue_metrics_d1bd92a3b039400cbafc60a7a5b1e52b_2025-05] creating index, cause [auto(bulk api)], templates [queue_metrics], shards [1]/[0]", "ecs.version": "1.2.0","service.name":"ES_ECS","event.dataset":"elasticsearch.server","process.thread.name":"elasticsearch[clearml][masterService#updateTask][T#1]","log.logger":"org.elasticsearch.cluster.metadata.MetadataCreateIndexService","elasticsearch.cluster.uuid":"lvIPB_h3RiWqbCvCA-1dbw","elasticsearch.node.id":"wEMvgjW3SUSt8Y8ls7aEyw","elasticsearch.node.name":"clearml","elasticsearch.cluster.name":"clearml"}
{"@timestamp":"2025-05-20T08:36:48.489Z", "log.level": "INFO",  "current.health":"GREEN","message":"Cluster health status changed from [YELLOW] to [GREEN] (reason: [shards started [[queue_metrics_d1bd92a3b039400cbafc60a7a5b1e52b_2025-05][0]]]).","previous.health":"YELLOW","reason":"shards started [[queue_metrics_d1bd92a3b039400cbafc60a7a5b1e52b_2025-05][0]]" , "ecs.version": "1.2.0","service.name":"ES_ECS","event.dataset":"elasticsearch.server","process.thread.name":"elasticsearch[clearml][masterService#updateTask][T#1]","log.logger":"org.elasticsearch.cluster.routing.allocation.AllocationService","elasticsearch.cluster.uuid":"lvIPB_h3RiWqbCvCA-1dbw","elasticsearch.node.id":"wEMvgjW3SUSt8Y8ls7aEyw","elasticsearch.node.name":"clearml","elasticsearch.cluster.name":"clearml"}
{"@timestamp":"2025-05-20T09:25:56.852Z", "log.level": "INFO", "message":"[events-log-d1bd92a3b039400cbafc60a7a5b1e52b] creating index, cause [auto(bulk api)], templates [events_log], shards [1]/[0]", "ecs.version": "1.2.0","service.name":"ES_ECS","event.dataset":"elasticsearch.server","process.thread.name":"elasticsearch[clearml][masterService#updateTask][T#11]","log.logger":"org.elasticsearch.cluster.metadata.MetadataCreateIndexService","elasticsearch.cluster.uuid":"lvIPB_h3RiWqbCvCA-1dbw","elasticsearch.node.id":"wEMvgjW3SUSt8Y8ls7aEyw","elasticsearch.node.name":"clearml","elasticsearch.cluster.name":"clearml"}
{"@timestamp":"2025-05-20T09:25:56.964Z", "log.level": "INFO",  "current.health":"GREEN","message":"Cluster health status changed from [YELLOW] to [GREEN] (reason: [shards started [[events-log-d1bd92a3b039400cbafc60a7a5b1e52b][0]]]).","previous.health":"YELLOW","reason":"shards started [[events-log-d1bd92a3b039400cbafc60a7a5b1e52b][0]]" , "ecs.version": "1.2.0","service.name":"ES_ECS","event.dataset":"elasticsearch.server","process.thread.name":"elasticsearch[clearml][masterService#updateTask][T#11]","log.logger":"org.elasticsearch.cluster.routing.allocation.AllocationService","elasticsearch.cluster.uuid":"lvIPB_h3RiWqbCvCA-1dbw","elasticsearch.node.id":"wEMvgjW3SUSt8Y8ls7aEyw","elasticsearch.node.name":"clearml","elasticsearch.cluster.name":"clearml"}

I need to ssh the instance, right?
I'll check it out.

ecc2, after I ssh-ed the instance.

Can you provide a standalone code snippet that reproduces this behaviour?

to close this thread, file server port wasn't configured
I added

        - IpProtocol: tcp
          FromPort: 8081
          ToPort: 8081
          CidrIp: 0.0.0.0/0

to cloudformation template, and it was resolved.

Thanks a bunch, guys
@<1722061389024989184:profile|ResponsiveKoala38> @<1523701070390366208:profile|CostlyOstrich36>

green open events-log-d1bd92a3b039400cbafc60a7a5b1e52b            Yh4BPGmgRZKU7STdCghmtw 1 0   96 0 175.1kb 175.1kb 175.1kb

I'm begining to think that there is something besides ClearML. I'll execute the training script on remote (SageMaker), instead of SageMaker local mode.

The.... are model-specific logs.

In ES container please run "curl -XGET localhost:9200/_cat/indices"

Can you provide the full log?

What is the status that you get for the "events-log-d1bd92a3b039400cbafc60a7a5b1e52b" index?

I would try it again.
